Bomb Calorimeter

Product Description

Standards:EN ISO 1716

Crucible made of stainless steel;
 2, Box paint treatment; all internal parts are made of stainless steel, corrosion-resistant, easy to clean;
 3, Ignition wire break is detection, and automatic ignition.
 4, The test procedure automatically turn off.
5, Test abnormalities has sound alarm.
6, Computer control system:
7, Control box with USB / RS232 serial port with an external brand desktop or laptop operating control; High degree of automation, test procedure safe and reliable, easy to operate;
Specification:

2, Oxygen bomb pressure range: 0.5 ~ 3.5MPa, no leakage. The bomb pressure 21Mpa.

3,Crucible:Φ 25mm, height 14-19 mm,thickness 1 mm. Stainless steel material;
4, Timer: accuracy of 0.5s;
5. Maximum power: 0.5KW;
6, Ambient temperature: (10 ~ 35) ºC, humidity ≤80%;
7, Heat capacity of the instrument: about 10000J / K;
8, Heat repeatability error: ≤0.2%;
9, Temperature range: (4.5-50) ºC;
10, Temperature detection: 0.0001 ºC resolution, using the PT100 sensor;
11, Inner cylinder volume: 2000ml; Oxygen bomb Sealing: oxygenation pressure 2.5 ~ 3.5MPa, no leakage;
12, Mixing power: 3W; Mixing speed: 375r/min

13,Ignition time:5s

14,Ignition voltage: DC 12V
15, Power supply voltage: AC220V ± 10% 50Hz
