Glow-Wire Test Apparatus

Product Description

Introduction:
Glow wire tester adopts chamber part and control part integrated design, convenient installation and debugging. Test chamber shell and important parts of stainless steel manufacturing, smoke, gas corrosion resistance; Automatic regulation control system adopts thyristor current, achieve the purpose of precise control temperature; Time, temperature digital display, easy observation records, stable and reliable use.

Model:FTech-IEC 60695

Standard:
IEC60695-2-10 ~ 13,UL 746A, IEC829, DIN695, VDE0471

Technical Parameters:
1. Dimension L710xW365xH760mm   Weight:50kg

2. Temperature range: room temp. ~ 1000 ºC,the  temp. is adjustable,

3. Temperature error: ± 10 ºC (500 ~ 750 ºC); ± 15 ºC (750 ~ 1000 ºC), temperature measuring instruments Accuracy ± 0.5 magnitude.

4. Temperature sensors: 0.5K type armored thermocouple, thermocouple imports.

5. Pressure applied to the specimen: 0.8N ~ 1.2N, and limit the indentation depth of at least 7mm.

6. Timing range: 0 to 99 minutes 99 seconds adjustable,

7. And having Shi burning time (Ta, generally according to standards set to 30), second holding burning time (Ti) and the flame goes out time (Te) of the timer;

8. Time error: ± 1s.

9. Ignited bedding layer: 10mm thick white pine wood, covered 12g / m2 ~ 30g / m2 standard tissue paper, from under the glow wire 200mm ± 5mm

10. Instrument operation is simple, stable and reliable temperature measurement system, and automatic temperature compensation.

11. Power supply: AC240VŒ50Hz
