Vertical Tray Cable Fire Test Apparatus

Vertical Tray Cable Fire Test Apparatus

Product Details:

  • Weight 200 Kilograms (kg)
  • Warranty 1 year
  • Supply Ability : 10 Set Per Month
1 INR/Set

Price And Quantity

  • 1000.00 - 9000.00 INR/Set
  • 1 Set
  • 1 INR/Set

Product Specifications

  • 1 year
  • 200 Kilograms (kg)

Trade Information

  • 10 Set Per Month
  • 1 Days

Product Description


This apparatus is designed according to UL1581 sect 1080.1~1080.14, and meet the criteria of VW-1(Vertical-specimen) Flame Test. It can be used to test of 1060 products wire and cable  FT1 and vertical burning test,1080 VW-1 test, 1061 test, 1090 horizontal test and 1100 horizontal specimen or FT2 test;to assess the flame spreading ability to combustible near by of cable or flexible wire when it caught fire.The whole test is carried out in a sealed test chamber with a volume of 4.54m.

 Test method: adjust the flame height to placed the specimen at the top of the flame, burning for 15 seconds, extinguished 15 seconds, repeat 5 times,then inspecting the burned situation of the specimen, it can be set the combustion, extinguish and repetition automatically.

1.The cabinet with a uni-body design, it would be easy to move into test room;

2.Touch-screen control system, convenient for operation;

3.5 test program for select;

4. Burner angle moved automatic.


Model FTech-UL1581


UL1581 sect 1060~1100

GB/T 12666.2-2008

ASTM D 5025

ASTM D 5207

Main Features

The test chamber is electrolytic plate electrostatic spraying, elegant appearance, and inside is roasted black

The tester is equipped with powerful exhaust fume extractor on the top, and open it when the test is completed, to air the exhaust automatically;during the test, this extractor is closed.

The glass viewing window is on the front box, allowing easy observation during the test.

The test chamber is equipped with sealed glove to operate the burner inside.

Test chamber size:  2.1M (l) *1.2M (w) *1.8M (h),The control chamber size:0.4m (l) *0.3m (w) *1.2m (h),

And available space: 4.4m3.
